Hayward SwimClear Cartridge 425 sq. ft. Pool Filter, W3C4030

Hayward SwimClear Cartridge 425 sq. ft. Pool Filter, W3C4030

Mfg #: W3C4030

SKU: HAY-05-823

UPC: 610377387910

1 review Write a Review
Secure transaction

Free Ground Shipping on Orders Over $99

Typically Ships in 1 to 2 Business Days


Hayward C4030 SwimClear(TM) Top Manifold Large Capacity Cartridge Filter; 425 sq-ft, 150 gpm, 50 psi

Wish there was a way to clean your pool's filtration system without pouring gallons of water into the environment? The SwimClear large-capacity cartridge filter delivers. No backwashing; instead, you just rinse the filter elements with your garden hose, saving you up to 2,500 gallons of water every season. Choose from 225, 325, 425 or 525 square feet of heavy-duty, dirt-holding capacity for extra-long cleaning cycles; this can translate to up to an entire season without cleaning. Another energy-efficient benefit is that the SwimClear doesn't require a multi-port valve, thereby using less electricity SwimClear filter tanks are created from new, stronger reinforced co-polymer for the ultimate in strength, durability and long life.


  • Top manifold configuration provides excellent filtration and hydraulic performance for reduced cost of operation
  • Cleanable cartridge elements eliminate the requirement for backwashing
  • Filter tanks are made from the most durable materials to meet the demands of the toughest applications and environmental conditions
  • Low-profile tank base makes removal of cartridge elements fast and simple
  • Heavy-duty, tamper-proof, one piece flange clamp securely fastens tank top and bottom and allows quick access to all internal components
  • CPVC 2" or 2.5" union connections provide maximum hydraulic performance with 2" plumbing



Application For in-ground pools, in-ground pool/spa combinations, in-ground spas
Brand Hayward
CartonWeight 69 lbs
Dimensions 24 inches W x 52.5 inches H
FilterElement Reinforced polyester
FilterTank High-strength, injection-molded durable glass reinforced copolymer
FiltrationArea 425 sq-ft
FlowRate 150 gpm
ItemName Hayward SwimClear(TM) Multi-Element Cartridge Filter
MaximumWorkingPressure 50 psi
StandardsApprovals NSF Listed
SubBrand SwimClear(TM)
Turnover 72000 gal at 8 hrs, 90000 gal at 10 hrs
Type In Ground Pool Filters

Operational Manual

1 Reviews

  • Posted by Kenny Brewer on Jan 31 2021


    Hayward Swimclear

    The customer service really were great and I would recommend them to anyone. I needed a new quality filter quickly and they recommended this one to me. I will do business here again! Thanks
