Description
Century(R) STS1152R 2-Speed Full-Rated Two-Compartment Pool Filter Motor; 1.5/0.25 HP; 3450/1725 RPM; 230 V; 56J; Threaded Shaft
Features
- Manufactured by Regal Beloit EPC, Inc.
- Service Factor: 1.3
- 9.0/3.3A
- Open Drip Proof
- 2-Compartment NEMA C-Face
- 50 Degrees C
- 303 Stainless Steel Threaded Shaft
- Auto Protector
Specifications
| Ambient Temperature | 50 deg C |
| Bearing Type | Sealed Ball |
| Brand | Regal Beloit |
| Diameter | 6-1/2 Inch |
| Duty Cycle | Continuous |
| Efficiency Group | High |
| Enclosure Design | Open Dripproof |
| Finish Color | Prime Coat Black |
| Flange Material | Aluminum |
| Frame | 56J |
| Frequency Rating | 60 Hz |
| Full Load Amps | 9.0/3.3 A |
| HP | 1.5/0.25 |
| Insulation Class | B |
| Item | Two-Compartment Pool Filter Motor |
| Motor Design | Capacitor Start/Run |
| Motor Shaft Rotation | CCWPE |
| Motor Thermal Protection | Auto |
| Mounting Type | C-Face |
| Number of Speed | 2-Speed |
| Overall Length | 13.06 Inch |
| Phase | 1-Phase |
| RPM | 3450/1725 |
| Service Factor | 1.30 |
| Shaft Design | Threaded |
| Shaft Diameter | 5/8 Inch |
| Shaft Length | 2-9/16 Inch |
| Shaft Material | 304 Stainless Steel |
| Standards Approvals | UL 1081 Approved, UL Recognized (E25022), CSA Certified (LR43341), Meets California Energy Commission Appliance Regulations 2008 |
| Sub Brand | Century® |
| Thrust Horsepower | 1.95 |
| Type | Full-Rated, K |
| Voltage Rating | 230 V |
Resources
Used On
- Hayward Max-Flo II SP2700X Pump Parts )
- Jacuzzi Magnum Pump Parts
- Jandy HHP/HHPU Pump Parts
- Jandy JHP/JHPU Pump Parts
